Product Description
The LS24GT is a fully gigabit unmanaged Ethernet switch independently developed by Codian Communications. It offers 24 10/100/1000M auto-sensing RJ45 ports. Each RJ45 port supports MDI/MDIX auto-sensing and wire-speed forwarding.This device is plug-and-play, requires no configuration, and is easy and convenient to use. It is the ideal choice for security monitoring and wireless coverage in hotels, campuses, factory dormitories, and small and medium-sized enterprises.
Specifications
Downlink Ports 24*10/100M RJ45 ports | Uplink ports |
Total Power Supply | LED Indicator PWR, Link / Act |
Transmission Mode
IEEE802.3 full duplex flow control
| Backplane Bandwidth 48Gbps |
Packet Forwarding Rate 35.71Mpps | MAC Address 4K |
Port lightning protection 4KV | Standard Protocol IEEE802.3i 10 BASE-T IEEE802.3u 100 BASE-TX IEEE802.3ab 1000 BASE-T |
Power Supply AC100-240V 50/60Hz | Size 270mm × 181mm × 44mm |
Working Temperature 0℃～45℃ | Storage Temperature - 20℃～70℃ |
Product Performance
● Large cache design ensures smooth playback of high-definition videos without lag
● Supports IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control
● Each RJ45 port supports MDI/MDIX auto-sensing and wire-speed forwarding functionality
Product Reliability
● The host is designed with low power consumption and natural heat dissipation to ensure stable operation of the product.
● The operating temperature range of 0 to 45℃ enhances the product's stability in a wide temperature environment.
Simple operation
● Plug and play, no configuration required, simple and convenient
● Users can easily understand the device's working status through the power indicator (Power) and port status indicator (Link/Act)
